The SCSI MDR 14Pin Male to 3xRCA Cable is part of the Breakout Cable range and is supplied made to order from our factory in Dongguan. A breakout assembly that converts a 14-pin MDR interface into three RCA connections, typically used to bring analogue video or trigger signals out of a frame grabber to standard laboratory equipment.
How this SCSI MDR 14Pin Male to 3xRCA Cable is built
Every unit is inspected before dispatch and ships with a test report, so incoming inspection becomes a document check rather than a re-test. Material compliance is documented against RoHS and REACH.
Key features
- Converts 14-pin MDR to three RCA plugs
- Individually shielded coaxial legs
- Flexible strain-relieved breakout boot
- Custom leg lengths and connector types available
Technical specifications
| Input | SCSI MDR 14-pin, male |
|---|---|
| Output | 3 x RCA, male |
| Shielding | Individual coax |
| Length | Made to order |
| Boot | Moulded breakout |
| Compliance | RoHS, REACH |
| Part number | A0701413XXX01 |
| Minimum order | 10 pcs |
| Compliance | RoHS and REACH compliant materials |
Typical applications
Frame grabber video breakout, trigger distribution and laboratory test rigs.
Ordering information
- Minimum order quantity: 10 pcs
- Availability: Made to order
- Lead time: 5–7 working days
- Sample service: samples for engineering validation are dispatched within 24 hours on stock items.
- Trade terms: FOB, EXW, CIF and DDP are all supported.
Custom configurations are available on request — alternative lengths, pin-outs, shielding arrangements and overmoulding can all be engineered to your drawing. Send the specification to King@KinKuo.com and our engineering team will confirm feasibility and pricing.
Quality assurance
KINKUO operates an ISO 9001:2015 certified quality system. Production runs through in-process inspection at every station, covering continuity, dielectric strength, insulation resistance and visual criteria. Finished scsi cables are verified against the drawing before packing, and a test report accompanies every shipment.
Cable construction and routing
Most faults in SCSI-format cable assemblies are not connector failures. They are shield terminations that were never completed, pair assignments that differ from the original, or assemblies used in moving applications they were never designed for.
- Confirm the hood type matches the retention method on the mating connector — screw and latch are not interchangeable in service.
- Specify double shielding where the cable runs near drive cabling or radio equipment.
- State the actual bend radius if the cable moves. A cable carrier radius below specification shortens life dramatically.
- Ask for matched pair lengths on multi-pair assemblies; uncontrolled length differences cause signal skew.
- Label both ends of multi-channel assemblies so field replacement does not risk a mis-wired connection.
Common questions
How do I choose between ABS and zinc hoods?
ABS is lighter and lower cost and suits general signal cabling. Die-cast zinc gives real shielding mass, which matters where the cable runs alongside drives or in electrically noisy cabinets.
Can you match an existing cable assembly exactly?
Send us the assembly, a drawing, or clear photographs of both ends and any markings. We will confirm the construction, pin-out and shielding before quoting.
Understanding the specification
The figures in the table above are not independent of one another. Read together they describe how this SCSI MDR 14Pin will behave in service, and where the practical limits sit once it is installed in equipment rather than tested on a bench.
- Input (SCSI MDR 14-pin, male):
- Output (3 × RCA, male):
- Shielding (Individual coax): Shielding only works when it is terminated. A shield that stops short of the connector shell leaves the signal path exposed to whatever the cabinet is radiating.
- Length (Made to order): Length should be the shortest that meets the routing requirement. Extra cable adds loss, capacitance and cost without adding capability.
- Boot (Moulded breakout):
- Compliance (RoHS, REACH): Compliance covers the material declarations your quality system will ask for. The declarations are available for every part number we supply.
Selecting a SCSI cable assembly
Most faults in SCSI-format cables are not connector failures. They are shield terminations that were never completed, pair assignments that differ from the original, or assemblies used in moving applications they were never designed for.
Confirm the retention method first. Screw and latch hoods are not interchangeable in service, and choosing the wrong one either slows maintenance or allows a cable to work loose under vibration.
Shielding comes next. Where a cable runs near drive cabling or radio equipment, double shielding with the shield bonded to the connector shell is not an upgrade — it is the baseline for a link that has to hold a differential signal reliably.
Finally, state the bend radius if the cable moves. A carrier radius below specification shortens life dramatically, and the resulting failure appears as an intermittent fault long before it becomes a hard one. Matched pair lengths matter too on multi-pair assemblies; uncontrolled length differences translate directly into signal skew.
Packaging, delivery and documentation
This item is made to order with a minimum order quantity of 10 pcs and a stated lead time of 5–7 working days. Orders ship on FOB, EXW, CIF or DDP terms as agreed at order confirmation, with real-time tracking provided once the shipment is booked.
Packaging is specified to survive international freight rather than to minimise volume. Connectors are supplied in anti-static packaging with pin protection where the contact geometry requires it; cable assemblies are coiled to a radius that respects the flex specification and secured so the assembly cannot move in transit. Both ends are labelled on multi-channel assemblies so a field replacement cannot be mis-wired.
Every shipment is accompanied by a test report covering continuity, dielectric strength, insulation resistance and any application-specific measurement performed. Where your quality system requires material declarations, batch traceability or joint sampling and sealing, confirm the requirement at the enquiry stage and we will build it into the order rather than adding it after production.
Further questions
Can I get a sample before committing to a production order?
Yes. Samples for engineering validation are dispatched within 24 hours for stocked items, and within the quoted production lead time for made-to-order assemblies. Every sample ships with its test report so that your validation is based on measured performance rather than on appearance.
What happens if the part does not fit the application?
Send us the mating half, a photograph or the equipment model and we will identify why. In most cases the answer is a different keying or coupling variant of the same family rather than a completely different product, and we would rather resolve it before you place a volume order than after.
Do you hold stock for repeat orders?
Stocked lines are held with safety quantity, and made-to-order tooling is retained so a repeat order does not repeat the tooling cost. For scheduled programmes we can agree a call-off arrangement that keeps material allocated against your forecast.
How this cable assembly is manufactured and tested
Cable stock is inspected on receipt for conductor stranding, shield coverage, jacket concentricity and print legibility, because these properties determine the electrical behaviour of the finished assembly far more than the connector does. Reel-level certificates are retained for traceability.
Assembly is carried out on calibrated equipment with the shield terminated to the connector shell around the full circumference. On assemblies with individually shielded pairs, each pair shield is terminated as well — this is the detail that separates a cable which holds a differential signal from one that works on a bench and drops frames in a cabinet. Pair lengths are matched where the assembly carries differential channels.
Testing covers continuity and short checking across every conductor, dielectric strength, and insulation resistance. High-speed and Camera Link assemblies are additionally verified with TDR impedance analysis, which confirms characteristic impedance along the length and locates any discontinuity introduced by the termination. Flex-rated constructions are qualified against the stated bend radius and travel distance rather than a generic figure.
Finished assemblies are coiled to a radius that respects the flex specification, labelled at both ends on multi-channel products, and packed so that the assembly cannot move in transit. The test report for the batch accompanies the shipment.
Warranty, returns and technical support
Cable assemblies are warranted against defects in materials and workmanship that appear under normal use for a period of 30 days from delivery, or for the period stated on the order confirmation if different. Where a verified defect is found, we will at our option repair, replace or refund the affected goods. The warranty does not cover failure arising from installation below the specified bend radius, use outside the published temperature or voltage ratings, or damage caused by pulling the assembly by its connector.
Returns require a return authorisation before shipment, and goods should be retained in their original condition pending inspection. Stocked items returned unused in original packaging may be accepted within 30 days subject to a restocking assessment; assemblies built to a customer drawing are not returnable unless defective.
Technical support is provided by the same engineers who handle the specification, not by a separate call centre. If a SCSI MDR 14Pin behaves unexpectedly in service, send us the installation detail — cable length, routing, environment and the symptom pattern — and we will work through the likely causes with you. Enquiries are answered within two hours during business days, and on-site technical support can be arranged for programmes where that is more practical than remote diagnosis.
Ordering checklist
To quote accurately and avoid a second iteration, we need the part number or the original manufacturer reference, the quantity required for validation and for production, the required delivery date, and the destination country so that the correct Incoterm can be applied. Where the item is a replacement for an obsolete part, a photograph of the existing connector and the equipment model will usually let us confirm the equivalent without a sample.
If your quality system requires material declarations, batch traceability, joint sampling and sealing, or a first-article inspection report, state that at the enquiry stage. These can all be accommodated, but retrofitting them into a production schedule costs more time than building them in from the start.
Technical documents
The original drawings and datasheets for this part are available to download. They are the documents issued by the manufacturer and are the reference to quote against when confirming a specification or a cross-reference.
If you need a document that is not listed here — a material declaration, a test report for a specific batch, or a dimensioned drawing in a different format — send the request to King@KinKuo.com and we will confirm availability.
Why source this part from KINKUO
We manufacture rather than resell, which means the part you receive is built on our own calibrated equipment by the same team that engineers it. That removes the margin stacking of a trading chain and keeps lead times predictable. Established in 2010, we supply scsi cables to customers across South China, East China, Japan, Europe and North America.
